The valve uses hydraulic pressure signals to trigger mechanical switching. This design allows seamless integration with hydraulic control systems commonly used in oilfield equipment.
The valve features two operating positions and five ports, enabling it to control airflow in multiple directions. This configuration is commonly used for operating double-acting pneumatic cylinders.
Once activated by the hydraulic signal, the valve changes the direction of compressed air flow, allowing pneumatic actuators to extend or retract efficiently.
Designed for industrial environments, the valve structure ensures stable operation, strong sealing performance, and long service life.
Using a hydraulic-controlled pneumatic valve offers several advantages:
Precise pneumatic directional control
Easy integration with hydraulic systems
Reliable switching performance
High durability in harsh environments
Reduced risk of system failure
These advantages make the valve an important component in oilfield drilling and industrial pneumatic systems.
As a professional supplier of oilfield control equipment, we provide hydraulic-controlled pneumatic valves designed to meet different system requirements.
Customization options include:
Different connection sizes (e.g., 1/4")
Various pressure ratings
Special sealing materials
Custom configurations for specific control systems
Our engineering team can provide technical assistance to help ensure seamless integration into your pneumatic-hydraulic control system.
